XH7132A Vertical Machining Center
1.Specifications
|
Item |
Unit |
Specification |
|
Table travel(X、Y、Z) |
mm |
620×350×500 |
|
Table size |
mm |
920×320 |
|
Number/Width/Distance of T-slot |
mm |
3-14-85 |
|
Distance from spindle nose to table surface |
mm |
100-600 |
|
Distance from spindle axis to column guideway |
mm |
420 |
|
Taper of spindle |
BT40 | |
|
Spindle speed range |
r/min |
40-6000rpm |
|
Spindle motor power |
kw |
Servo 5.5 |
|
Rapid feed speed(X、Y、Z) |
m/min |
24/24/18 |
|
Feed speed (X、Y、Z) |
mm/min |
2.5-6000 |
|
Tool magazine capability |
16 | |
|
Max. weight of tool |
mm |
φ120×200 |
|
Max. weight of tool |
kg |
8 |
|
Positioning accuracy |
mm |
±0.005 JIS |
|
Repeat positioning accuracy |
mm |
±0.003 JIS |
|
Overall dimension |
mm |
2020×1970×2160 |
|
Machine weight |
kg |
3200 |
2.Performance characteristics
◇ X、Y、Z Three-axis ultra-wide hard rail to ensure rigidity of machine processing.
◇ Taiwan ball screw.
◇ Japan NSK Bearings.
◇ Taiwan high-speed high-precision spindle.
◇ Taiwan magazine, Tool storage capacity 16.
3.Standard configuration
◇ GSK25i
◇ 16 hats style magazine.
◇ RS232 communication interface.
4.Select configuration
◇ CNC system optional: FANUC oi mate-MD, Siemens 828D, HNC-808M, KND-2000M.
◇ 16 disc magazine.
◇ CNC fourth axis.
◇ Automatic chip removal system.
